Eco Friendly Plastic Sheet Extrusion Machine With Twin Screw Extruder

Basic Information
Place of Origin: CHINA
Brand Name: YAOAN
Certification: CE
Model Number: 1000mm
Minimum Order Quantity: 1
Packaging Details: WOODEN BOX
Delivery Time: 30-90 DAYS
Payment Terms: TT,LC
Supply Ability: 100 SETS PER MONTH
Material: PET Flakes Capacity: 300-500kg/hr
Screw: Twin Screw LD: 44:1
Motor: SIEMENS Warranty: 1 Year
High Light:

pet sheet extrusion line

,

plastic sheet manufacturing machine

High Quality Dry Free PET Sheet Extrusion Machine Line With Twin Screw Extruder



PET sheet production line is for producing defferent PET sheets, the production line is consist of Single screw extruder / Parallel double screw extruder, Hydraulic screen changer, T-die, three roller calender, Haul-off machine, widing machine and cutter, etc.



SPECIFICATIONS FOR PET SHEET EXTRUSION LINE
Model
AF-120-1200 high exfficient
AF-75/40-GF1000 Non crystalline
Extruder Model
120/35 single screw
75/40 parallel double screw
Main motor power
110KW
132KW
Products thickness
0.15-1.5mm
0.15-1.5mm
Capacity
500kg/h
600kg/h



Main Features

Possibility to process 100% PET flakes and/or reground (thermoforming skeleton) material with initial humidity up to 1.5% (residual moisture) with no need for dehumidifying process. Raw material pre-treatments are very complex and timeconsuming (hours).


User-friendly feeding and dosing equipment


Dosing systems designed are outstanding for reliability, user friendliness, and maintenance-free construction, resulting in easier management and configuration of raw material feeding and dosing ancillary equipment.



Vented Single Screw design is the best solution for recycling flakes processing. It could get great balance between sheet quality and energy saving. we have successful experiences to provide you full solution for this.



Co-rotating screws featuring a special profile to ensure PET polymer gentle processing, with no thermal and hydrolytic degradation, thus resulting in excellent melt thermal control.
